View Issue Details

Jump to NotesJump to History
IDProjectCategoryView StatusDate SubmittedLast Update
0001516channel: kernel/el9kernel-ltpublic2025-03-08 08:592025-03-16 22:48
Reporterelrepo@mx.zzux.com Assigned Totoracat
PrioritynormalSeveritymajorReproducibilityalways
Status assignedResolutionopen
Platformamd64OSCentOS StreamOS Version9
Summary0001516: Update to 'kernel-lt.x86_64-6.1.130-1.el9.elrepo' causes start failure in the VM with vfio passthrough
DescriptionThere are two libvirt/qemu log files attached,

'fail'
with error
qemu-kvm: -device {"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}: vfio 0000:00:1b.0: failed to setup container for group 0: memory listener initialization failed: Region pc.rom: vfio_container_dma_map(0x56392f24a680, 0xc0000, 0x20000, 0x7fccf8400000) = -12 (Cannot allocate memory)

and 'ok', after reboot & select 6.1.129 kernel in the GRUB menu.


device 0000:00:1b.0 is
8086:8d20 Audio device: Intel Corporation C610/X99 series chipset HD Audio Controller (rev 05)
Steps To Reproduceuname -r
6.1.130-1.el9.elrepo.x86_64

dnf list installed qemu-kvm
qemu-kvm.x86_64 17:9.1.0-15.el9
TagsNo tags attached.
Attached Files
fail.txt (5,343 bytes)
2025-03-08 12:08:27.016+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.130-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890 \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.config \
/usr/libexec/qemu-kvm \
-name guest=WIN-1234567890,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-WIN-1234567890/master-key.aes"}' \
-machine pc-i440fx-rhel7.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,hpet=off,acpi=on \
-accel kvm \
-cpu Broadwell,hv-time=on,kvmclock=off,hv-relaxed=on,hv-vapic=on,hv-spinlocks=0x1fff \
-m size=67108864k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":68719476736}' \
-overcommit mem-lock=off \
-smp 8,sockets=1,dies=1,clusters=1,cores=4,threads=2 \
-uuid 3624e98b-8823-435f-92c6-88a0e217cb3a \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=21,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,clock=vm \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global PIIX4_PM.disable_s3=1 \
-global PIIX4_PM.disable_s4=1 \
-boot strict=on \
-device '{"driver":"virtio-scsi-pci","id":"scsi0","bus":"pci.0","addr":"0x3"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/vhdd/WIN-1234567890/BOOT.VHD","aio":"native","node-name":"libvirt-3-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","multifunction":true,"addr":"0x4","drive":"libvirt-3-storage","id":"virtio-disk0","bootindex":1,"write-cache":"off"}' \
-blockdev '{"driver":"host_device","filename":"/dev/disk/by-id/wwn-0x50000a7f7b01cd02e","aio":"native","node-name":"libvirt-2-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","addr":"0x4.0x1","drive":"libvirt-2-storage","id":"virtio-disk1","bootindex":2,"write-cache":"on"}' \
-blockdev '{"driver":"host_device","filename":"/dev/disk/by-id/wwn-0x500005bd8afeb031","aio":"native","node-name":"libvirt-1-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","addr":"0x4.0x2","drive":"libvirt-1-storage","id":"virtio-disk2","bootindex":3,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"22","vhost":true,"vhostfd":"24","id":"hostnet0"}' \
-device '{"driver":"virtio-net-pci","netdev":"hostnet0","id":"net0","mac":"52:54:00:11:22:33","bus":"pci.0","multifunction":true,"addr":"0x5"}' \
-netdev '{"type":"tap","fd":"25","vhost":true,"vhostfd":"26","id":"hostnet1"}' \
-device '{"driver":"virtio-net-pci","netdev":"hostnet1","id":"net1","mac":"52:54:00:44:55:66","bus":"pci.0","addr":"0x5.0x1"}' \
-device '{"driver":"virtio-input-host-pci","id":"input0","evdev":"/dev/input/by-path/platform-i8042-serio-0-event-kbd","bus":"pci.0","addr":"0x11.0x1"}' \
-device '{"driver":"virtio-input-host-pci","id":"input1","evdev":"/dev/input/by-path/platform-i8042-serio-1-event-mouse","bus":"pci.0","multifunction":true,"addr":"0x11"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-device '{"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev1","bus":"pci.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:04:00.0","id":"hostdev2","bus":"pci.0","multifunction":true,"addr":"0x6","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:04:00.1","id":"hostdev3","bus":"pci.0","addr":"0x6.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-08 12:08:27.016+0000: Domain id=1 is tainted: deprecated-config (machine type 'pc-i440fx-rhel7.6.0')
2025-03-08T12:08:27.271087Z qemu-kvm: warning: Machine type 'pc-i440fx-rhel7.6.0' is deprecated: machines from the previous RHEL major release are subject to deletion in the next RHEL major release
2025-03-08T12:08:27.310510Z qemu-kvm: -device {"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-08T12:08:27.310539Z qemu-kvm: -device {"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-08T12:08:27.696849Z qemu-kvm: -device {"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-08T12:08:35.876471Z qemu-kvm: -device {"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}: vfio 0000:00:1b.0: failed to setup container for group 0: memory listener initialization failed: Region pc.rom: vfio_container_dma_map(0x56392f24a680, 0xc0000, 0x20000, 0x7fccf8400000) = -12 (Cannot allocate memory)
2025-03-08 12:08:36.102+0000: shutting down, reason=failed
fail.txt (5,343 bytes)
ok.txt (5,160 bytes)
2025-03-08 12:12:18.272+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.129-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890 \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-WIN-1234567890/.config \
/usr/libexec/qemu-kvm \
-name guest=WIN-1234567890,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-WIN-1234567890/master-key.aes"}' \
-machine pc-i440fx-rhel7.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,hpet=off,acpi=on \
-accel kvm \
-cpu Broadwell,hv-time=on,kvmclock=off,hv-relaxed=on,hv-vapic=on,hv-spinlocks=0x1fff \
-m size=67108864k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":68719476736}' \
-overcommit mem-lock=off \
-smp 8,sockets=1,dies=1,clusters=1,cores=4,threads=2 \
-uuid 3624e98b-8823-435f-92c6-88a0e217cb3a \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=21,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,clock=vm \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global PIIX4_PM.disable_s3=1 \
-global PIIX4_PM.disable_s4=1 \
-boot strict=on \
-device '{"driver":"virtio-scsi-pci","id":"scsi0","bus":"pci.0","addr":"0x3"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/vhdd/WIN-1234567890/BOOT.VHD","aio":"native","node-name":"libvirt-3-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","multifunction":true,"addr":"0x4","drive":"libvirt-3-storage","id":"virtio-disk0","bootindex":1,"write-cache":"off"}' \
-blockdev '{"driver":"host_device","filename":"/dev/disk/by-id/wwn-0x50000a7f7b01cd02e","aio":"native","node-name":"libvirt-2-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","addr":"0x4.0x1","drive":"libvirt-2-storage","id":"virtio-disk1","bootindex":2,"write-cache":"on"}' \
-blockdev '{"driver":"host_device","filename":"/dev/disk/by-id/wwn-0x500005bd8afeb031","aio":"native","node-name":"libvirt-1-storage","read-only":false,"cache":{"direct":true,"no-flush":false}}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.0","addr":"0x4.0x2","drive":"libvirt-1-storage","id":"virtio-disk2","bootindex":3,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"22","vhost":true,"vhostfd":"24","id":"hostnet0"}' \
-device '{"driver":"virtio-net-pci","netdev":"hostnet0","id":"net0","mac":"52:54:00:11:22:33","bus":"pci.0","multifunction":true,"addr":"0x5"}' \
-netdev '{"type":"tap","fd":"25","vhost":true,"vhostfd":"26","id":"hostnet1"}' \
-device '{"driver":"virtio-net-pci","netdev":"hostnet1","id":"net1","mac":"52:54:00:44:55:66","bus":"pci.0","addr":"0x5.0x1"}' \
-device '{"driver":"virtio-input-host-pci","id":"input0","evdev":"/dev/input/by-path/platform-i8042-serio-0-event-kbd","bus":"pci.0","addr":"0x11.0x1"}' \
-device '{"driver":"virtio-input-host-pci","id":"input1","evdev":"/dev/input/by-path/platform-i8042-serio-1-event-mouse","bus":"pci.0","multifunction":true,"addr":"0x11"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-device '{"driver":"vfio-pci","host":"0000:00:1b.0","id":"hostdev0","bus":"pci.0","addr":"0x1b","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev1","bus":"pci.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:04:00.0","id":"hostdev2","bus":"pci.0","multifunction":true,"addr":"0x6","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:04:00.1","id":"hostdev3","bus":"pci.0","addr":"0x6.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-08 12:12:18.273+0000: Domain id=1 is tainted: deprecated-config (machine type 'pc-i440fx-rhel7.6.0')
2025-03-08T12:12:18.467260Z qemu-kvm: warning: Machine type 'pc-i440fx-rhel7.6.0' is deprecated: machines from the previous RHEL major release are subject to deletion in the next RHEL major release
2025-03-08T12:12:27.325099Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:12:27.338071Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:15:43.761203Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:15:43.765097Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:15:44.289265Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:15:44.289399Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T12:17:12.136679Z qemu-kvm: terminating on signal 15 from pid 1221 (/usr/sbin/virtqemud)
2025-03-08 12:17:13.367+0000: shutting down, reason=shutdown
ok.txt (5,160 bytes)

Activities

elrepo@mx.zzux.com

2025-03-08 10:03

reporter   ~0010342

I also cannot start VM on another host. See log in the attachment.
centos-stream9-2.log (7,921 bytes)
2025-03-08 14:56:16.599+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.130-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-6-centos-stream9-2 \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-6-centos-stream9-2/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-6-centos-stream9-2/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-6-centos-stream9-2/.config \
/usr/libexec/qemu-kvm \
-name guest=centos-stream9-2,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-6-centos-stream9-2/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/usr/share/edk2/ovmf/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/centos-stream9-2_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,hpet=off,acpi=on \
-accel kvm \
-cpu host,migratable=on \
-m size=1572864k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":1610612736}' \
-overcommit mem-lock=off \
-smp 2,sockets=2,cores=1,threads=1 \
-uuid 1f3c063e-9440-49bf-a682-77f43ba3fb71 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"pcie-root-port","port":16,"chassis":1,"id":"pci.1","bus":"pcie.0","multifunction":true,"addr":"0x2"}' \
-device '{"driver":"pcie-root-port","port":17,"chassis":2,"id":"pci.2","bus":"pcie.0","addr":"0x2.0x1"}' \
-device '{"driver":"pcie-root-port","port":18,"chassis":3,"id":"pci.3","bus":"pcie.0","addr":"0x2.0x2"}' \
-device '{"driver":"pcie-root-port","port":19,"chassis":4,"id":"pci.4","bus":"pcie.0","addr":"0x2.0x3"}' \
-device '{"driver":"pcie-root-port","port":20,"chassis":5,"id":"pci.5","bus":"pcie.0","addr":"0x2.0x4"}' \
-device '{"driver":"pcie-root-port","port":21,"chassis":6,"id":"pci.6","bus":"pcie.0","addr":"0x2.0x5"}' \
-device '{"driver":"pcie-root-port","port":22,"chassis":7,"id":"pci.7","bus":"pcie.0","addr":"0x2.0x6"}' \
-device '{"driver":"pcie-root-port","port":23,"chassis":8,"id":"pci.8","bus":"pcie.0","addr":"0x2.0x7"}' \
-device '{"driver":"pcie-root-port","port":24,"chassis":9,"id":"pci.9","bus":"pcie.0","multifunction":true,"addr":"0x3"}' \
-device '{"driver":"pcie-root-port","port":25,"chassis":10,"id":"pci.10","bus":"pcie.0","addr":"0x3.0x1"}' \
-device '{"driver":"pcie-root-port","port":26,"chassis":11,"id":"pci.11","bus":"pcie.0","addr":"0x3.0x2"}' \
-device '{"driver":"pcie-root-port","port":27,"chassis":12,"id":"pci.12","bus":"pcie.0","addr":"0x3.0x3"}' \
-device '{"driver":"pcie-root-port","port":28,"chassis":13,"id":"pci.13","bus":"pcie.0","addr":"0x3.0x4"}' \
-device '{"driver":"pcie-root-port","port":29,"chassis":14,"id":"pci.14","bus":"pcie.0","addr":"0x3.0x5"}' \
-device '{"driver":"qemu-xhci","p2":15,"p3":15,"id":"usb","bus":"pci.2","addr":"0x0"}' \
-device '{"driver":"virtio-serial-pci","id":"virtio-serial0","bus":"pci.3","addr":"0x0"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/linux.vhd","node-name":"libvirt-1-storage","read-only":false}' \
-device '{"driver":"virtio-blk-pci","bus":"pci.4","addr":"0x0","drive":"libvirt-1-storage","id":"virtio-disk0","bootindex":1}' \
-netdev '{"type":"tap","fd":"28","vhost":true,"vhostfd":"30","id":"hostnet0"}' \
-device '{"driver":"virtio-net-pci","netdev":"hostnet0","id":"net0","mac":"52:54:00:a9:a7:ef","bus":"pci.1","addr":"0x0"}' \
-device '{"driver":"usb-tablet","id":"input0","bus":"usb.0","port":"1"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:02.0","id":"hostdev0","bus":"pcie.0","multifunction":true,"addr":"0x4","rombar":1}' \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev1","bus":"pcie.0","addr":"0x14","rombar":0}' \
-device '{"driver":"virtio-balloon-pci","id":"balloon0","bus":"pci.5","addr":"0x0"}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-08T14:56:16.934616Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T14:56:16.934890Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T14:56:17.089919Z qemu-kvm: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-08T14:56:17.089943Z qemu-kvm: vfio_container_dma_map(0x559dcec39a80, 0xc0000, 0x20000, 0x7f488c200000) = -12 (Cannot allocate memory)
qemu: hardware error: vfio: DMA mapping failed, unable to continue
CPU #0:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000906e9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=0
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
CPU #1:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000906e9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=1
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
2025-03-08 14:56:17.152+0000: shutting down, reason=failed
centos-stream9-2.log (7,921 bytes)

toracat

2025-03-12 02:53

administrator   ~0010345

I glanced through the changelog for kernel-lt-6.1.130 but could not find anything obvious.

Will you be able to test-install kernel-ml and see if the issue persists? Or else, kernel-lt-6.1.131 should be out in the next few days, so you can give it a try.

elrepo@mx.zzux.com

2025-03-12 12:40

reporter   ~0010346

Yes, there is no the subject issue with the kernel-ml-6.13.6-1.el9.elrepo.x86_64.
Now only the version 130 is buggy.
I hope it will be ok in 131.

toracat

2025-03-13 22:38

administrator   ~0010350

kernel-lt-6.1.131 has just been released and is currently syncing to mirrors. Let's see if this one works.

elrepo@mx.zzux.com

2025-03-14 03:29

reporter   ~0010351

Now I tried both kernel-lt-6.1.131 & kernel-ml-6.13.7.
6.1.131 is with the same bug again.
Config & log files are in the attachment.
grub.cfg (3,424 bytes)
set pager=1

function load_video {
  if [ x$feature_all_video_module = xy ]; then
    insmod all_video
  else
    insmod efi_gop
    insmod efi_uga
    insmod ieee1275_fb
    insmod vbe
    insmod vga
    insmod video_bochs
    insmod video_cirrus
  fi
}

terminal_output console

set timeout_style=menu
set timeout=1

menuentry 'CentOS Stream (6.1.129-1.el9.elrepo.x86_64) 9' --class centos --unrestricted {
	load_video
	set gfxpayload=keep
	insmod gzio
	insmod part_msdos
	insmod xfs
	search --no-floppy --fs-uuid --set=root 27ec0a2c-d966-4804-903a-9ab2cf9d1710
	linux /boot/vmlinuz-6.1.129-1.el9.elrepo.x86_64 root=UUID=27ec0a2c-d966-4804-903a-9ab2cf9d1710 ro net.ifnames=0 biosdevname=0 edd=off dis_ucode_ldr mitigations=off intel_iommu=on selinux=0 audit=0 pci-stub.ids=1002:67ef,1002:aae0,1002:675f,1002:aa90,8086:a2c5,8086:a2a1,8086:a2f0,8086:a2a3 LANG=en_US.UTF-8
	initrd /boot/initramfs-6.1.129-1.el9.elrepo.x86_64.img
}
menuentry 'CentOS Stream (6.1.130-1.el9.elrepo.x86_64) 9' --class centos --unrestricted {
	load_video
	set gfxpayload=keep
	insmod gzio
	insmod part_msdos
	insmod xfs
	search --no-floppy --fs-uuid --set=root 27ec0a2c-d966-4804-903a-9ab2cf9d1710
	linux /boot/vmlinuz-6.1.130-1.el9.elrepo.x86_64 root=UUID=27ec0a2c-d966-4804-903a-9ab2cf9d1710 ro net.ifnames=0 biosdevname=0 edd=off dis_ucode_ldr mitigations=off intel_iommu=on selinux=0 audit=0 pci-stub.ids=1002:67ef,1002:aae0,1002:675f,1002:aa90,8086:a2c5,8086:a2a1,8086:a2f0,8086:a2a3 LANG=en_US.UTF-8
	initrd /boot/initramfs-6.1.130-1.el9.elrepo.x86_64.img
}
menuentry 'CentOS Stream (6.1.131-1.el9.elrepo.x86_64) 9' --class centos --unrestricted {
	load_video
	set gfxpayload=keep
	insmod gzio
	insmod part_msdos
	insmod xfs
	search --no-floppy --fs-uuid --set=root 27ec0a2c-d966-4804-903a-9ab2cf9d1710
	linux /boot/vmlinuz-6.1.131-1.el9.elrepo.x86_64 root=UUID=27ec0a2c-d966-4804-903a-9ab2cf9d1710 ro net.ifnames=0 biosdevname=0 edd=off dis_ucode_ldr mitigations=off intel_iommu=on selinux=0 audit=0 pci-stub.ids=1002:67ef,1002:aae0,1002:675f,1002:aa90,8086:a2c5,8086:a2a1,8086:a2f0,8086:a2a3 LANG=en_US.UTF-8
	initrd /boot/initramfs-6.1.131-1.el9.elrepo.x86_64.img
}
menuentry 'CentOS Stream (6.13.6-1.el9.elrepo.x86_64) 9' --class centos --unrestricted {
	load_video
	set gfxpayload=keep
	insmod gzio
	insmod part_msdos
	insmod xfs
	search --no-floppy --fs-uuid --set=root 27ec0a2c-d966-4804-903a-9ab2cf9d1710
	linux /boot/vmlinuz-6.13.6-1.el9.elrepo.x86_64 root=UUID=27ec0a2c-d966-4804-903a-9ab2cf9d1710 ro net.ifnames=0 biosdevname=0 edd=off dis_ucode_ldr mitigations=off intel_iommu=on selinux=0 audit=0 pci-stub.ids=1002:67ef,1002:aae0,1002:675f,1002:aa90,8086:a2c5,8086:a2a1,8086:a2f0,8086:a2a3 LANG=en_US.UTF-8
	initrd /boot/initramfs-6.13.6-1.el9.elrepo.x86_64.img
}
menuentry 'CentOS Stream (6.13.7-1.el9.elrepo.x86_64) 9' --class centos --unrestricted {
	load_video
	set gfxpayload=keep
	insmod gzio
	insmod part_msdos
	insmod xfs
	search --no-floppy --fs-uuid --set=root 27ec0a2c-d966-4804-903a-9ab2cf9d1710
	linux /boot/vmlinuz-6.13.7-1.el9.elrepo.x86_64 root=UUID=27ec0a2c-d966-4804-903a-9ab2cf9d1710 ro net.ifnames=0 biosdevname=0 edd=off dis_ucode_ldr mitigations=off intel_iommu=on selinux=0 audit=0 pci-stub.ids=1002:67ef,1002:aae0,1002:675f,1002:aa90,8086:a2c5,8086:a2a1,8086:a2f0,8086:a2a3 LANG=en_US.UTF-8
	initrd /boot/initramfs-6.13.7-1.el9.elrepo.x86_64.img
}

default='CentOS Stream (6.13.7-1.el9.elrepo.x86_64) 9'
grub.cfg (3,424 bytes)
W7_UEFI.xml (3,872 bytes)
<!--
WARNING: THIS IS AN AUTO-GENERATED FILE. CHANGES TO IT ARE LIKELY TO BE
OVERWRITTEN AND LOST. Changes to this xml configuration should be made using:
  virsh edit W7_UEFI
or other application using the libvirt API.
-->

<domain type='kvm'>
  <name>W7_UEFI</name>
  <uuid>255565ef-9190-4f83-8365-649530f40cc5</uuid>
  <metadata>
    <libosinfo:libosinfo xmlns:libosinfo="http://libosinfo.org/xmlns/libvirt/domain/1.0">
      <libosinfo:os id="http://microsoft.com/win/7"/>
    </libosinfo:libosinfo>
  </metadata>
  <memory unit='KiB'>4194304</memory>
  <currentMemory unit='KiB'>4194304</currentMemory>
  <vcpu placement='static'>2</vcpu>
  <os>
    <type arch='x86_64' machine='pc-q35-rhel9.6.0'>hvm</type>
    <loader readonly='yes' secure='no' type='pflash' format='raw'>/data/libvirt/ovmf2023/OVMF_CODE.fd</loader>
    <nvram template='/data/libvirt/ovmf2023/OVMF_VARS.fd' templateFormat='raw' format='raw'>/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd</nvram>
    <boot dev='hd'/>
    <bootmenu enable='no'/>
  </os>
  <features>
    <acpi/>
    <apic/>
    <hyperv mode='custom'>
      <vendor_id state='on' value='1234567890ab'/>
    </hyperv>
    <kvm>
      <hidden state='on'/>
    </kvm>
  </features>
  <cpu mode='custom' match='exact' check='partial'>
    <model fallback='allow'>IvyBridge</model>
    <topology sockets='1' dies='1' clusters='1' cores='2' threads='1'/>
  </cpu>
  <clock offset='utc'>
    <timer name='rtc' tickpolicy='catchup'/>
    <timer name='pit' tickpolicy='delay'/>
    <timer name='kvmclock' present='no'/>
  </clock>
  <on_poweroff>destroy</on_poweroff>
  <on_reboot>restart</on_reboot>
  <on_crash>restart</on_crash>
  <pm>
    <suspend-to-mem enabled='no'/>
    <suspend-to-disk enabled='no'/>
  </pm>
  <devices>
    <emulator>/usr/libexec/qemu-kvm</emulator>
    <disk type='file' device='disk'>
      <driver name='qemu' type='raw' cache='unsafe' discard='unmap'/>
      <source file='/data/libvirt/images/W10_TST_RAM_128GB.VHD'/>
      <target dev='sda' bus='sata'/>
      <address type='drive' controller='0' bus='0' target='0' unit='0'/>
    </disk>
    <controller type='sata' index='0'>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/>
    </controller>
    <controller type='pci' index='0' model='pcie-root'/>
    <controller type='pci' index='1' model='dmi-to-pci-bridge'>
      <model name='i82801b11-bridge'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/>
    </controller>
    <controller type='usb' index='0' model='none'/>
    <interface type='direct'>
      <mac address='52:54:00:07:d9:36'/>
      <source dev='lan0' mode='bridge'/>
      <model type='e1000'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/>
    </interface>
    <input type='mouse' bus='ps2'/>
    <input type='keyboard' bus='ps2'/>
    <audio id='1' type='none'/>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <source>
        <address domain='0x0000' bus='0x00' slot='0x14' function='0x0'/>
      </source>
      <rom bar='off'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x14' function='0x0'/>
    </hostdev>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <source>
        <address domain='0x0000' bus='0x01' slot='0x00' function='0x0'/>
      </source>
      <rom bar='on'/>
      <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0' multifunction='on'/>
    </hostdev>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <source>
        <address domain='0x0000' bus='0x01' slot='0x00' function='0x1'/>
      </source>
      <rom bar='off'/>
      <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x1'/>
    </hostdev>
    <watchdog model='itco' action='reset'/>
    <memballoon model='none'/>
  </devices>
</domain>
W7_UEFI.xml (3,872 bytes)
W7_UEFI-6.1.129.log (3,688 bytes)
2025-03-13 11:59:12.121+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.129-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.config \
/usr/libexec/qemu-kvm \
-name guest=W7_UEFI,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-W7_UEFI/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/ovmf2023/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,acpi=on \
-accel kvm \
-cpu IvyBridge,kvmclock=off,hv-vendor-id=1234567890ab,kvm=off \
-m size=4194304k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":4294967296}' \
-overcommit mem-lock=off \
-smp 2,sockets=1,dies=1,clusters=1,cores=2,threads=1 \
-uuid 255565ef-9190-4f83-8365-649530f40cc5 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"i82801b11-bridge","id":"pci.1","bus":"pcie.0","multifunction":true,"addr":"0x1"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/W10_TST_RAM_128GB.VHD","node-name":"libvirt-1-storage","read-only":false,"discard":"unmap","cache":{"direct":false,"no-flush":true}}' \
-device '{"driver":"ide-hd","bus":"ide.0","drive":"libvirt-1-storage","id":"sata0-0-0","bootindex":1,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"28","id":"hostnet0"}' \
-device '{"driver":"e1000","netdev":"hostnet0","id":"net0","mac":"52:54:00:07:d9:36","bus":"pcie.0","addr":"0x3"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev0","bus":"pcie.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.0","id":"hostdev1","bus":"pci.1","multifunction":true,"addr":"0x0","rombar":1}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.1","id":"hostdev2","bus":"pci.1","addr":"0x0.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-13T11:59:14.908404Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T11:59:14.908905Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T12:03:17.600322Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T12:03:17.604488Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T12:59:23.900859Z qemu-kvm: terminating on signal 15 from pid 750 (/usr/sbin/virtqemud)
2025-03-13 12:59:25.308+0000: shutting down, reason=shutdown
W7_UEFI-6.1.129.log (3,688 bytes)
W7_UEFI-6.1.130.log (6,367 bytes)
2025-03-08 14:53:09.873+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.130-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.config \
/usr/libexec/qemu-kvm \
-name guest=W7_UEFI,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-W7_UEFI/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/ovmf2023/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,acpi=on \
-accel kvm \
-cpu IvyBridge,kvmclock=off,hv-vendor-id=1234567890ab,kvm=off \
-m size=4194304k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":4294967296}' \
-overcommit mem-lock=off \
-smp 2,sockets=1,dies=1,clusters=1,cores=2,threads=1 \
-uuid 255565ef-9190-4f83-8365-649530f40cc5 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"pcie-root-port","port":8,"chassis":1,"id":"pci.1","bus":"pcie.0","addr":"0x1"}' \
-device '{"driver":"x3130-upstream","id":"pci.2","bus":"pci.1","addr":"0x0"}' \
-device '{"driver":"xio3130-downstream","port":0,"chassis":3,"id":"pci.3","bus":"pci.2","addr":"0x0"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/W10_TST_RAM_128GB.VHD","node-name":"libvirt-1-storage","read-only":false,"discard":"unmap","cache":{"direct":false,"no-flush":true}}' \
-device '{"driver":"ide-hd","bus":"ide.0","drive":"libvirt-1-storage","id":"sata0-0-0","bootindex":1,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"28","id":"hostnet0"}' \
-device '{"driver":"e1000","netdev":"hostnet0","id":"net0","mac":"52:54:00:07:d9:36","bus":"pcie.0","addr":"0x3"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:02.0","id":"hostdev0","bus":"pcie.0","addr":"0x2","rombar":0,"romfile":"/data/libvirt/bios/i915/i915ovmf.rom"}' \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev1","bus":"pcie.0","addr":"0x14","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-08T14:53:10.451852Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T14:53:10.452046Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-08T14:53:10.620302Z qemu-kvm: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-08T14:53:10.620323Z qemu-kvm: vfio_container_dma_map(0x5621ca6e5400, 0xc0000, 0x20000, 0x7fd550600000) = -12 (Cannot allocate memory)
qemu: hardware error: vfio: DMA mapping failed, unable to continue
CPU #0:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000306a9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=0
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
CPU #1:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000306a9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=1
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
2025-03-08 14:53:10.787+0000: shutting down, reason=failed
W7_UEFI-6.1.130.log (6,367 bytes)
W7_UEFI-6.1.131.log (6,269 bytes)
2025-03-14 06:30:02.740+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.1.131-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.config \
/usr/libexec/qemu-kvm \
-name guest=W7_UEFI,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-W7_UEFI/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/ovmf2023/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,acpi=on \
-accel kvm \
-cpu IvyBridge,kvmclock=off,hv-vendor-id=1234567890ab,kvm=off \
-m size=4194304k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":4294967296}' \
-overcommit mem-lock=off \
-smp 2,sockets=1,dies=1,clusters=1,cores=2,threads=1 \
-uuid 255565ef-9190-4f83-8365-649530f40cc5 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"i82801b11-bridge","id":"pci.1","bus":"pcie.0","multifunction":true,"addr":"0x1"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/W10_TST_RAM_128GB.VHD","node-name":"libvirt-1-storage","read-only":false,"discard":"unmap","cache":{"direct":false,"no-flush":true}}' \
-device '{"driver":"ide-hd","bus":"ide.0","drive":"libvirt-1-storage","id":"sata0-0-0","bootindex":1,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"28","id":"hostnet0"}' \
-device '{"driver":"e1000","netdev":"hostnet0","id":"net0","mac":"52:54:00:07:d9:36","bus":"pcie.0","addr":"0x3"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev0","bus":"pcie.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.0","id":"hostdev1","bus":"pci.1","multifunction":true,"addr":"0x0","rombar":1}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.1","id":"hostdev2","bus":"pci.1","addr":"0x0.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-14T06:30:05.516007Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-14T06:30:05.520010Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-14T06:30:05.567369Z qemu-kvm: VFIO_MAP_DMA failed: Cannot allocate memory
2025-03-14T06:30:05.567386Z qemu-kvm: vfio_container_dma_map(0x5606e5847e80, 0xc0000, 0x20000, 0x7fad36600000) = -12 (Cannot allocate memory)
qemu: hardware error: vfio: DMA mapping failed, unable to continue
CPU #0:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000306a9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=0
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
CPU #1:
EAX=00000000 EBX=00000000 ECX=00000000 EDX=000306a9
ESI=00000000 EDI=00000000 EBP=00000000 ESP=00000000
EIP=0000fff0 EFL=00000002 [-------] CPL=0 II=0 A20=1 SMM=0 HLT=1
ES =0000 00000000 0000ffff 00009300
CS =f000 ffff0000 0000ffff 00009b00
SS =0000 00000000 0000ffff 00009300
DS =0000 00000000 0000ffff 00009300
FS =0000 00000000 0000ffff 00009300
GS =0000 00000000 0000ffff 00009300
LDT=0000 00000000 0000ffff 00008200
TR =0000 00000000 0000ffff 00008b00
GDT=     00000000 0000ffff
IDT=     00000000 0000ffff
CR0=60000010 CR2=00000000 CR3=00000000 CR4=00000000
DR0=0000000000000000 DR1=0000000000000000 DR2=0000000000000000 DR3=0000000000000000
DR6=00000000ffff0ff0 DR7=0000000000000400
EFER=0000000000000000
FCW=037f FSW=0000 [ST=0] FTW=00 MXCSR=00001f80
FPR0=0000000000000000 0000 FPR1=0000000000000000 0000
FPR2=0000000000000000 0000 FPR3=0000000000000000 0000
FPR4=0000000000000000 0000 FPR5=0000000000000000 0000
FPR6=0000000000000000 0000 FPR7=0000000000000000 0000
XMM00=0000000000000000 0000000000000000 XMM01=0000000000000000 0000000000000000
XMM02=0000000000000000 0000000000000000 XMM03=0000000000000000 0000000000000000
XMM04=0000000000000000 0000000000000000 XMM05=0000000000000000 0000000000000000
XMM06=0000000000000000 0000000000000000 XMM07=0000000000000000 0000000000000000
2025-03-14 06:30:06.803+0000: shutting down, reason=failed
W7_UEFI-6.1.131.log (6,269 bytes)
W7_UEFI-6.13.6.log (3,687 bytes)
2025-03-13 15:58:48.759+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.13.6-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.config \
/usr/libexec/qemu-kvm \
-name guest=W7_UEFI,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-W7_UEFI/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/ovmf2023/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,acpi=on \
-accel kvm \
-cpu IvyBridge,kvmclock=off,hv-vendor-id=1234567890ab,kvm=off \
-m size=4194304k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":4294967296}' \
-overcommit mem-lock=off \
-smp 2,sockets=1,dies=1,clusters=1,cores=2,threads=1 \
-uuid 255565ef-9190-4f83-8365-649530f40cc5 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"i82801b11-bridge","id":"pci.1","bus":"pcie.0","multifunction":true,"addr":"0x1"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/W10_TST_RAM_128GB.VHD","node-name":"libvirt-1-storage","read-only":false,"discard":"unmap","cache":{"direct":false,"no-flush":true}}' \
-device '{"driver":"ide-hd","bus":"ide.0","drive":"libvirt-1-storage","id":"sata0-0-0","bootindex":1,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"28","id":"hostnet0"}' \
-device '{"driver":"e1000","netdev":"hostnet0","id":"net0","mac":"52:54:00:07:d9:36","bus":"pcie.0","addr":"0x3"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev0","bus":"pcie.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.0","id":"hostdev1","bus":"pci.1","multifunction":true,"addr":"0x0","rombar":1}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.1","id":"hostdev2","bus":"pci.1","addr":"0x0.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-13T15:58:51.531439Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T15:58:51.531892Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T16:01:09.517892Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T16:01:09.518461Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-13T17:52:35.795425Z qemu-kvm: terminating on signal 15 from pid 720 (/usr/sbin/virtqemud)
2025-03-13 17:52:37.215+0000: shutting down, reason=shutdown
W7_UEFI-6.13.6.log (3,687 bytes)
W7_UEFI-6.13.7.log (3,471 bytes)
2025-03-14 06:34:25.792+0000: starting up libvirt version: 10.10.0, package: 7.el9 (builder@centos.org, 2025-02-17-21:17:04, ), qemu version: 9.1.0qemu-kvm-9.1.0-15.el9, kernel: 6.13.7-1.el9.elrepo.x86_64, hostname: localhost
LC_ALL=C \
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin \
HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI \
XDG_DATA_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.local/share \
XDG_CACHE_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.cache \
XDG_CONFIG_HOME=/var/lib/libvirt/qemu/domain-1-W7_UEFI/.config \
/usr/libexec/qemu-kvm \
-name guest=W7_UEFI,debug-threads=on \
-S \
-object '{"qom-type":"secret","id":"masterKey0","format":"raw","file":"/var/lib/libvirt/qemu/domain-1-W7_UEFI/master-key.aes"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/ovmf2023/OVMF_CODE.fd","node-name":"libvirt-pflash0-storage","auto-read-only":true,"discard":"unmap"}' \
-blockdev '{"node-name":"libvirt-pflash0-format","read-only":true,"driver":"raw","file":"libvirt-pflash0-storage"}' \
-blockdev '{"driver":"file","filename":"/var/lib/libvirt/qemu/nvram/W7_UEFI_VARS.fd","node-name":"libvirt-pflash1-storage","read-only":false}' \
-machine pc-q35-rhel9.6.0,usb=off,dump-guest-core=off,memory-backend=pc.ram,pflash0=libvirt-pflash0-format,pflash1=libvirt-pflash1-storage,acpi=on \
-accel kvm \
-cpu IvyBridge,kvmclock=off,hv-vendor-id=1234567890ab,kvm=off \
-m size=4194304k \
-object '{"qom-type":"memory-backend-ram","id":"pc.ram","size":4294967296}' \
-overcommit mem-lock=off \
-smp 2,sockets=1,dies=1,clusters=1,cores=2,threads=1 \
-uuid 255565ef-9190-4f83-8365-649530f40cc5 \
-display none \
-no-user-config \
-nodefaults \
-chardev socket,id=charmonitor,fd=27,server=on,wait=off \
-mon chardev=charmonitor,id=monitor,mode=control \
-rtc base=utc,driftfix=slew \
-global kvm-pit.lost_tick_policy=delay \
-no-shutdown \
-global ICH9-LPC.disable_s3=1 \
-global ICH9-LPC.disable_s4=1 \
-boot menu=off,strict=on \
-device '{"driver":"i82801b11-bridge","id":"pci.1","bus":"pcie.0","multifunction":true,"addr":"0x1"}' \
-blockdev '{"driver":"file","filename":"/data/libvirt/images/W10_TST_RAM_128GB.VHD","node-name":"libvirt-1-storage","read-only":false,"discard":"unmap","cache":{"direct":false,"no-flush":true}}' \
-device '{"driver":"ide-hd","bus":"ide.0","drive":"libvirt-1-storage","id":"sata0-0-0","bootindex":1,"write-cache":"on"}' \
-netdev '{"type":"tap","fd":"28","id":"hostnet0"}' \
-device '{"driver":"e1000","netdev":"hostnet0","id":"net0","mac":"52:54:00:07:d9:36","bus":"pcie.0","addr":"0x3"}' \
-audiodev '{"id":"audio1","driver":"none"}' \
-global ICH9-LPC.noreboot=off \
-watchdog-action reset \
-device '{"driver":"vfio-pci","host":"0000:00:14.0","id":"hostdev0","bus":"pcie.0","addr":"0x14","rombar":0}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.0","id":"hostdev1","bus":"pci.1","multifunction":true,"addr":"0x0","rombar":1}' \
-device '{"driver":"vfio-pci","host":"0000:01:00.1","id":"hostdev2","bus":"pci.1","addr":"0x0.0x1","rombar":0}' \
-sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny \
-msg timestamp=on
2025-03-14T06:34:28.498573Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-14T06:34:28.499356Z qemu-kvm: vfio: Cannot reset device 0000:00:14.0, no available reset mechanism.
2025-03-14T06:35:27.028425Z qemu-kvm: terminating on signal 15 from pid 725 (/usr/sbin/virtqemud)
2025-03-14 06:35:28.440+0000: shutting down, reason=shutdown
W7_UEFI-6.13.7.log (3,471 bytes)

toracat

2025-03-16 22:48

administrator   ~0010354

So, kernel-ml does not have the problem that you see with kernel-lt-6.1.130. It looks as though some patch(es) that was(were) backported from the mainline kernel to stable kernel 6.1 caused the issue. If this is indeed the case, either the "bad patch" needs to be deleted or additional patch(es) need to be backported to fix it.

Since we, ELRepo, cannot modify or fix the code, you'd have to report this to kernel developers. Here's the link for their bugzilla:

https://bugzilla.kernel.org/enter_bug.cgi?product=Linux

I see a few patches that might be related to this bug in the upcoming release of kernel 6.1. Therefore you might want to wait for the next update and see if the problem persists.

Issue History

Date Modified Username Field Change
2025-03-08 08:59 elrepo@mx.zzux.com New Issue
2025-03-08 08:59 elrepo@mx.zzux.com Status new => assigned
2025-03-08 08:59 elrepo@mx.zzux.com Assigned To => toracat
2025-03-08 08:59 elrepo@mx.zzux.com File Added: fail.txt
2025-03-08 08:59 elrepo@mx.zzux.com File Added: ok.txt
2025-03-08 10:03 elrepo@mx.zzux.com Note Added: 0010342
2025-03-08 10:03 elrepo@mx.zzux.com File Added: centos-stream9-2.log
2025-03-08 13:00 toracat Status assigned => acknowledged
2025-03-12 02:53 toracat Note Added: 0010345
2025-03-12 12:40 elrepo@mx.zzux.com Note Added: 0010346
2025-03-13 22:38 toracat Note Added: 0010350
2025-03-13 22:38 toracat Status acknowledged => assigned
2025-03-14 03:29 elrepo@mx.zzux.com Note Added: 0010351
2025-03-14 03:29 elrepo@mx.zzux.com File Added: grub.cfg
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI.xml
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI-6.1.129.log
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI-6.1.130.log
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI-6.1.131.log
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI-6.13.6.log
2025-03-14 03:29 elrepo@mx.zzux.com File Added: W7_UEFI-6.13.7.log
2025-03-16 22:48 toracat Note Added: 0010354
